Power-handling nominal (RMS): 400 W
Power-handling, program: 800 W
Power-handling, peak: 1200 W
Nominal impedance: 8 ohms
Max SPL: 128 dB half space (@10% THD)
Sensitivity 1W/1m: 104 dB half space
Frequency response +/- 3 dB: 70 Hz – 19 kHz
Frequency response -10 dB: 63 Hz – 19 kHz
Low/Mid Speaker: 1x 12"
HF Driver: 1"
HF horn: 60° x 40° CD horn
HF protection (passive): Dyn. protective circuit
Crossover frequency: 2.3 kHz, 12 dB/oct.
Connections: 2x Speakon NL4
Angles up: 32°
Handles: 1, integrated
Enclosure: MDF
Grille: Metal grille with black acoustic foam
Finish: Acrylic enamel, black
Optional accessories: Protective cover
Dimensions (WxHxD): 39 x 55.5 x 38 cm
Weight: 16.3 kg/ 35.9 lbs.
