Power-handling nominal (RMS): 300 W
Power-handling, program: 600 W
Power-handling, peak: 1200 W
Nominal impedance: 8 ohms
Max SPL: 126 dB half space (@10% THD)
Sensitivity 1W/1m: 99 dB half space
Frequency response +/- 3 dB: 95 Hz - 19 kHz
Frequency response -10 dB: 80 Hz - 19 kHz
Low/Mid Speaker: 1x 10"
HF Driver: 1"
HF horn: 90° x 60° CD horn
HF protection (passive): Dyn. protective circuit
Crossover frequency: 2.2 kHz, 12 dB/oct.
Connections: 2x Speakon NL4
Angles up: 35°
Pole mount: DuoTilt 3/7
Rigging points: 3x M8
Handles: 1, integrated
Enclosure: MDF
Grille: Metal grille with black acoustic foam
Finish: Acrylic enamel, black
Optional accessories: Protective cover, Satellite Add-On M20, Adjustable pole M20
Dimensions (WxHxD): 32 x 48.5 x 30 cm
Weight: 12.5 kg / 2.6 lbs
